Rerode R1+ Knowledge Base: Initial Setup & Assembly Guide

Rerode R1+ Knowledge Base: Initial Setup & Assembly Guide

Unboxing, Assembly & Initial Setup Guide

Meta Description

Learn how to unbox, assemble, and set up your Rerode R1+ with this complete step-by-step guide. Covers assembly, battery installation, TFT display functions, ride modes, regenerative braking (EABS), and key specifications to get your bike ready for its first ride.

Introduction

Congratulations on your new Rerode R1+.

This knowledge base walks you through the complete unboxing, assembly, and initial setup of your bike. You'll learn how to install the major components, connect the battery, configure the TFT display, understand the ride modes, and familiarize yourself with the bike's features before your first ride.

What's Included in the Box

Every Rerode R1+ includes the following:

  • Rerode R1+ Electric Dirt Bike
  • Battery
  • Charger with protective carrying case
  • Front wheel spacers
  • Front number plate
  • Front fender
  • Left and right CNC foot pegs
  • Tool kit
  • Owner's manual
  • Keys
  • Rerode hat
  • Work gloves
  • Portable electric air compressor
  • Portable fan

These accessories are included to help you assemble, maintain, and enjoy your Rerode R1+ right out of the box.

Tools Required

Most of the bike can be assembled using basic hand tools.

Required tools include:

  • 3 mm Allen wrench
  • 4 mm Allen wrench
  • 12 mm wrench or socket
  • 14 mm wrench
  • Two 19 mm wrenches or sockets
  • Zip ties
  • Torque wrench (recommended)



Assembly Procedure

Step 1 — Install the Handlebars

  1. Remove the handlebar clamps.
  2. Position the handlebars.
  3. Tighten the four clamp bolts evenly.
  4. Verify proper alignment before fully tightening.

Step 2 — Install the Throttle

  • Slide the throttle onto the handlebars.
  • Position it against the bar end.
  • Back it off slightly so it rotates freely.
  • Tighten the clamp.
  • Confirm the throttle snaps back freely before riding.

Step 3 — Install the Front Brake Lever

  1. Loosen the brake clamp.
  2. Position the brake lever.
  3. Tighten securely.

Step 4 — Organize the Wiring

Before installing the front number plate:

  • Bundle the wiring neatly using the supplied zip ties.
  • Ensure nothing binds or rubs while turning the handlebars.

Keeping the wiring organized improves appearance and prevents unnecessary wear.

Step 5 — Install the Front Fender

The Rerode R1+ uses a unique four-bolt front fender design.

Bolt sizes:

  • Front bolts: 4 mm
  • Rear bolts: 3 mm

The four-bolt mounting system provides greater rigidity than a traditional three-bolt design.

Step 6 — Install the Front Number Plate

  1. Install the upper mounting bolt.
  2. Secure the lower section using the supplied zip ties.

Step 7 — Install the Front Wheel

  1. Install both wheel spacers.
  2. Position the wheel.
  3. Slide the axle through.
  4. Install the axle nut.
  5. Tighten using two 19 mm wrenches.
  6. Tighten both axle pinch bolts evenly.

Axle pinch bolt torque: 9 N·m

Always verify both pinch bolts are installed and tightened before riding.

Step 8 — Install the Foot Pegs

Install each foot peg so it folds rearward.

This allows the peg to fold backward if it strikes a rock or obstacle, reducing the chance of damage.

Installation requires:

  • 12 mm wrench or socket
  • 14 mm wrench



Battery Installation

The battery ships disconnected for transportation.

Connecting the Battery

  1. Unlock and remove the seat using the supplied key.
  2. Release both battery compartment latches.
  3. Lift the battery cover.
  4. Connect the battery connector.
  5. Turn the battery breaker ON.
  6. Close the battery cover.
  7. Reinstall the seat.

The bike is now ready to power on.

Removing the Battery

Before removing the battery:

  1. Turn the breaker OFF.
  2. Disconnect the battery connector.
  3. Lift the battery straight upward.



Powering On the Bike

  1. Insert the key.
  2. Turn the ignition ON.
  3. Wait for the TFT display to boot.

The display shows:

  • Battery percentage
  • Vehicle speed
  • Ride mode
  • Trip information



Ride Modes

The Rerode R1+ features three selectable ride modes:

  • Eco
  • Sport
  • Sport+

To change ride modes:

  1. Exit Park Mode using the red button.
  2. Press and hold the mode button to cycle through:

Eco → Sport → Sport+

Sport+ is indicated in red on the TFT display.

Reverse

To activate Reverse:

  • Hold the Reverse button.
  • Apply throttle.

Horn

The horn button is located beneath the reverse control.



TFT Display Settings

Within 10 seconds of powering on the bike:

Press and hold the + and – buttons simultaneously.

The settings menu includes:

  • Backlight Brightness
  • Speed Units (MPH/KMH)
  • Gear Ratio
  • Wheel Size
  • EABS (Regenerative Braking)
  • Firmware Version



Display Information Screens

Press the Power button to cycle through:

  • Trip Meter
  • Odometer
  • Average Speed
  • Maximum Speed
  • Trip Time
  • Current Regen Setting

Resetting the Trip Meter

To reset Trip:

  1. Hold the + and – buttons.
  2. Select Trip Reset.
  3. Choose Yes.

The trip meter will reset to zero.



Regenerative Braking (EABS)

The TFT display allows you to adjust regenerative braking through the EABS menu.

Available settings:

  • G0
  • G1
  • G2
  • G3
  • G4

Increasing the setting increases regenerative braking strength.

For a detailed explanation of regen settings and operation, refer to:

Rerode R1 & R1+ Knowledge Base: How to Configure Regenerative Braking (EABS).



Rerode R1+ Specifications

  • Peak Power: 17 kW
  • Battery: 72V 40Ah
  • Peak Torque: 500 N·m
  • Top Speed: Approximately 60 mph
  • Suspension: FastAce Front & Rear
  • Brakes: DOT Hydraulic Disc Brakes
  • Wheel Size: 19"/18"



Aftermarket Compatibility

The Rerode R1+ shares many components with the Sur-Ron Light Bee platform, making aftermarket upgrades widely available.

Compatible upgrades include:

  • 16/19 wheelsets
  • Handlebars
  • Direct mount stems
  • Suspension
  • Foot pegs
  • Brake systems
  • Performance controllers
  • Graphics kits
  • Seat covers

Performance controllers and tuning solutions are already available from manufacturers like EBMX, allowing riders to further customize the R1+ to suit their riding style.



Summary

  • Assemble the bike using basic hand tools.
  • Install the handlebars, throttle, brake lever, front fender, number plate, front wheel, and foot pegs.
  • Connect the battery and switch the battery breaker ON before powering up.
  • The TFT display provides access to ride modes, trip data, display settings, and regenerative braking adjustments.
  • Three ride modes are available: Eco, Sport, and Sport+.
  • Reverse is activated by holding the Reverse button while applying throttle.
  • The TFT display allows adjustment of backlight brightness, speed units, wheel size, and EABS settings.
  • The R1+ produces 17 kW of peak power, features a 72V 40Ah battery, delivers 500 N·m of torque, and reaches approximately 60 mph.
  • Extensive aftermarket compatibility allows riders to customize the bike with upgraded wheels, suspension, brakes, controllers, graphics, and other accessories.
