Ventus V1+ Limited On Power? Here is the Fix!

1. Overview

This article explains how to restore full power on your Ventus V1+ if the bike is experiencing limited power output caused by an incorrect motor temperature sensor setting. By following this guide, you'll learn how to connect to your bike using the VTB App, update the motor temperature sensor setting, save the changes to the controller, and restore normal power output. If the issue persists after completing these steps, you'll also know what to check next.

2. Prerequisites

Before starting this procedure, ensure you have the following:

Required Permissions

• Access to the VTB App.

• Bluetooth enabled on your mobile device.

Software/Tools

• Latest version of the VTB App installed on your iOS or Android device.

Time Required

• Approximately 1 minute to complete.

Hardware/Components

• Ventus V1+ electric dirt bike.

• Smartphone or tablet with Bluetooth enabled.

• Bike battery with sufficient charge.

⚠️ Important: This procedure applies to Ventus V1+ models using the VTB App. Before making any changes, verify you are connected to the correct bike. Only modify the Motor Temperature Sensor setting described in this guide. Changing other controller parameters may affect the bike's performance or operation.

3. Step-by-Step Instructions (with Visuals)

Follow the steps below to restore full power on your Ventus V1+ using the VTB App. Be sure to complete each step in order.

3.1 Connect to the Bike

1. Download and open the VTB App on your mobile device.

2. Turn the Ventus V1+ on.

3. Tap Connect within the app.

4. Select your bike from the list of available Bluetooth devices.

5. Wait until the app indicates that the connection has been established.

Expected Result:
The VTB App is successfully connected to your Ventus V1+ and displays the main dashboard.

Screenshot:

Tips

• Ensure Bluetooth is enabled on your mobile device.

• Stay within Bluetooth range of the bike during the entire procedure.

• If the bike does not appear, close and reopen the app, then try connecting again.

3.2 Change the Motor Temperature Sensor Setting

1. From the main screen, open Parameter Settings.

2. Select Advanced Settings.

3. Scroll down and tap Motor.

4. Locate the Temperature Sensor setting.

5. Change the setting from its current value to None.

6. Tap Save.

7. Tap Save to Bike to write the changes to the controller.

Expected Result:
The updated Motor Temperature Sensor setting has been successfully saved to the bike.

Tips

• Only change the Temperature Sensor setting described in this guide.

• Always press Save to Bike after pressing Save, or the changes will not be applied.

• Wait for the confirmation message before continuing.

3.3 Restart and Verify Operation

1. Turn the bike OFF.

2. Wait approximately 5 seconds.

3. Turn the bike ON again.

4. Test the bike to verify that full power has been restored.

Expected Result:
The Ventus V1+ should now operate at normal power output.

Tips

• If the bike is still limited on power, verify that your controller's power settings are configured correctly.
